What's New in Onshape's Latest Update (April 19th, 2021)

It's April already, and we are back at it again with another update. We have made some Sheet Metal enhancements and a lot of great Drawing updates. Let's take a look!

CAD IMPROVEMENTS

SHEET METAL IMPROVEMENTS

The Sheet Metal model feature dialog now has collapsible group boxes to make it easier to navigate the options. It is separated out into groups named Selections, General, Material, and Relief.

Image: https://lh4.googleusercontent.com/gYkKlZRyUbuFHetE7ow6BtmAod4OnXlQNzy_5Ut2TLort5grx1SOMAn-nkV_j52D9ofJLdpzq6Aad9SXv7K9Mbj7AWqBAP2prHkjsOq3HT1b_JXan8JtQITF6ExT5FiC1E6bY98m

DISSOLVING SUBASSEMBLIES

You can promote the contents of a subassembly into a higher level assembly using the new Dissolve subassembly action.

DRAWING IMPROVEMENTS

AUXILIARY VIEW IMPROVEMENTS

Now, Auxiliary views can be created from a Section view.

Image: https://us.v-cdn.net/5022071/uploads/editor/8e/hazopmiomhxb.gif

REVISION TABLE IMPROVEMENTS

The revision description in a Revision table writes to the drawing custom property “Revision description.” This allows you to search for it in Onshape or even link to an external system.

SMART DIMENSION TOOL IMPROVEMENTS

The Smart Dimension tool has been enhanced to show wall thickness when dimensioning between two concentric circles. It also now adds a diameter symbol for the silhouetted edges of a cylindrical face.

VIEW LABELS

You can now add a view label to any drawing view from the View properties. The new label is attached and will move with the view when it is repositioned.

MOBILE IMPROVEMENTS

IOS ASSEMBLY CONFIGURATIONS

iOS now supports changing configurations within an assembly.

ENTERPRISE IMPROVEMENTS

AZURE SSO

Onshape is now included in the Azure Active Directory (AD) gallery. This simplifies the setup required to link the two together for Onshape Enterprise subscriptions. The Help documentation is updated with full instructions.

Image: https://lh6.googleusercontent.com/vA0p2qbmpbbdAmDVFJiTr3S83YX_7llZBojkO9UhiUxNKimcPsz3EZp9GygRfR8pP4nxEZRyp_HoQE608r4kEq0lEhiScxdaWb5GHamWQPLRtlyzDBQO7MviG9Jt-tiLBbEi1pmC

ONSHAPE LEARNING CENTER IMPROVEMENTS

ONSHAPE SURFACING TIPS AND BEST PRACTICES

A new technical briefing, Onshape Surfacing Tips and Best Practices, is now released to help you learn tips and tricks when modeling surfaces and curves in Onshape.

Image: https://us.v-cdn.net/5022071/uploads/editor/xn/natpy41mf5x7.jpg

GENERAL IMPROVEMENTS

COMPANY-WIDE EXPORT RULES

The previously released feature to set Export rules is now available as a company-wide setting for Professional and Enterprise level users.

Image: https://lh4.googleusercontent.com/rqCrWuzrDz1CLRK7zfET1mKfHtAEM-oMGmSXFt62vWnlwlPZB-ayCbE6tIPoWg4YnBqgmqsFt-QqQ1GD720SMyjfWg7i5L0xuJFMW2kPTBcR8YtirtTTwQd6wtbWHB5-Pw3WCfEM

PASSWORD REQUIREMENTS

As part of our ongoing effort to maintain the highest standards of security, we have updated the way new passwords are enforced. All new account passwords and password changes are now checked against the database at https://haveibeenpwned.com using a K-Anonymity check. Onshape cannot access the password for any account. All checks are done with hashed passwords that cannot be reversed by us. Passwords that have been compromised will be rejected even if they meet the complexity requirements. This change will not invalidate current account passwords.

Please review the NIST password guidelines for choosing appropriately secure passwords. Onshape also encourages all users to use two-factor authentication (2FA), but this is optional.

For a detailed list of all the changes in this update, please see the changelog.

Remember: The updates listed here are now live for all users when creating new Onshape Documents and over the next few days these features will also be available in Documents created before the date of this update.
